World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.
IS200TTSAG1A - Trip Solenoid Interface Board is available in stock which ships the same day.
IS200TTSAG1A - Trip Solenoid Interface Board comes in UNUSED as well as REBUILT condition.
To avail our best deals for IS200TTSAG1A - Trip Solenoid Interface Board, contact us and we will get back to you within 24 hours.
SPECIFICATIONS:
Part Number: IS200TTSAG1A
Manufacturer: General Electric
Series: Mark VI
Product Type: Trip Solenoid Interface Board
Number of channels: 12
Operating System: QNX
Common Mode Voltage Range: +5 V dc
Maximum Lead Resistance: 15Ω
Analog output current: 0-20 mA
Operating temperature: -30 to 65 °C
Size: 8.26 cm high x 4.18 cm
Repair: 3-7 Day
Availability: In Stock
Weight: 2 lbs
Country of Origin: United States
FUNCTIONAL DESCRIPTION:
IS200TTSAG1A is a Trip Solenoid Interface Board manufactured and designed by General Electric as part of the Mark VI Series used in GE Speedtronic Gas turbine Control Systems. A Trip Solenoid Interface Board is a device used in industrial control systems to interface between a control system and a trip solenoid. A trip solenoid is an electromechanical device used to trip or interrupt the power supply to a particular equipment or system in case of an abnormal condition or emergency. The interface board acts as a mediator between the control system and the trip solenoid, providing the necessary signals and control functions. It typically receives signals from the control system indicating the need to trip a particular device or system. Based on these signals, the interface board activates the trip solenoid, which in turn interrupts the power supply to the equipment or system.
FEATURES:
The features of a trip solenoid interface board can vary depending on the specific model and manufacturer. However, here are some common features that you may find:
Input/Output (I/O) Terminals: The interface board typically provides terminals for connecting to the control system. These terminals allow the board to receive signals from the control system indicating the need to trip a device or system and provide status feedback to the control system.
Relay Outputs: The board may include relay outputs that are used to activate the trip solenoid. These relays provide a switching mechanism to interrupt the power supply to the equipment or system.
Isolation and Protection: Trip solenoid interface boards often incorporate isolation circuitry to ensure electrical isolation between the control system and the high-power trip solenoid. This isolation helps protect the control system from voltage spikes, noise, or other electrical disturbances.
Diagnostic Capabilities: Some interface boards feature diagnostic capabilities to monitor the health and status of the board itself. This may include indicators or built-in tests that provide feedback on the board's operation and help identify any faults or issues.
Communication Protocols: Depending on the application and system requirements, the interface board may support various communication protocols for interfacing with the control system. Common protocols include Modbus, Profibus, Ethernet, or other proprietary protocols.
WOC has the largest stock of GE Speedtronic Gas Turbine Control System Replacement Parts. We can also repair your faulty boards. WORLD OF CONTROLS can also supply unused and rebuilt backed-up with a warranty. Our team of experts is available round the clock to support your OEM needs. Our team of experts at WOC is happy to assist you with any of your automation requirements. For pricing and availability on any parts and repairs, kindly get in touch with our team by phone or email.
FREQUENTLY ASKED QUESTIONS:
What is the purpose of a trip solenoid interface board?
The trip solenoid interface board serves as a mediator between a control system and a trip solenoid. It receives signals from the control system indicating the need to trip a device or system and activates the trip solenoid to interrupt the power supply accordingly.
What industries typically use trip solenoid interface boards?
Trip solenoid interface boards are commonly used in industries such as power generation, oil and gas, chemical plants, and manufacturing facilities where the protection of equipment and systems is crucial.
Can trip solenoid interface boards be integrated with existing control systems?
Yes, trip solenoid interface boards are designed to be compatible with various control systems and can be integrated into existing control architectures. They often support common communication protocols, allowing for seamless integration with the control system.
