DS200ADPBG1A - Genius I/O Adapter Board

SPECIFICATIONS:

Part Number: DS200ADPBG1A
Manufacturer: General Electric
Series: Drive Control
Product Type: Genius I/O Adapter Board
Power Requirements: +5 V dc, 6 A
Number of relay channels: 12
Power supply voltage: 28 V dc
Mounting: DIN-rail mounting
Technology: Surface mount
Operating temperature: -30 to +65°C
Size: 15.9 cm high x 17.8 cm
Repair: 3-7 Day
Availability: In Stock
Country of Origin: United States
Manual: GEH-6195F

FUNCTIONAL DESCRIPTION:

DS200ADPBG1A is a Genius I/O Adapter Board manufactured and designed by General Electric as part of the Mark V Series used in GE Drive Control Systems. A Genius I/O Adapter Board is a piece of hardware designed to interface with or adapt various input and output (I/O) devices in a computer or electronic system. The Genius I/O Adapter Board is an essential component in various electronic systems, designed to act as an interface between a microcontroller or embedded system and a range of input/output (I/O) devices. It serves as a bridge to facilitate the communication between external sensors, actuators, and the central processing unit (CPU) or microcontroller. By providing multiple I/O ports, the board allows users to connect and manage multiple devices simultaneously, enabling the efficient processing of inputs (e.g., from sensors) and outputs (e.g., motors or displays). This type of adapter is particularly useful in automation, robotics, and IoT applications, where seamless interaction between hardware components is required.

These may include I2C, SPI, UART, or GPIO (General Purpose Input/Output), allowing for flexible and efficient data transmission between connected devices and the controlling system. Depending on the system requirements, the adapter board can be used for both analog and digital signals, which makes it highly adaptable to different types of sensors and actuators. This broad compatibility ensures that the board can be incorporated into a wide range of projects, from simple automation tasks to more complex embedded systems designs.

FUNCTIONS OF GENIUS I/O ADAPTER BOARD:

• I2C (Inter-Integrated Circuit): A multi-master, multi-slave protocol for communication with sensors and peripheral devices. The board includes I2C buses, often with pull-up resistors, to ensure proper communication between devices.

• SPI (Serial Peripheral Interface): A faster, full-duplex protocol used for communication with sensors, SD cards, and other peripherals. The board may have SPI connectors (MISO, MOSI, SCK, and CS) to interface with SPI devices.

• UART (Universal Asynchronous Receiver-Transmitter): A serial communication protocol used for data transfer over two wires (TX and RX). The board may include UART interfaces for communication with other microcontrollers or serial devices.

• GPIO (General Purpose Input/Output): These are digital pins used for simple on/off signals. They are configured to read high/low states or to trigger actions such as turning on a relay or activating an LED.

• Filtering: Using low-pass filters (capacitors) or high-pass filters to remove noise from analog signals, ensuring that only the intended frequency components pass through.

• Amplification: Using operational amplifiers (op-amps) to amplify weak signals (such as from a temperature sensor) to a level that the microcontroller can effectively read.

WOC has the largest stock of GE Drive Control System Replacement Parts. We can also repair your faulty boards and supply unused and rebuilt boards backed up with a warranty. Our team of experts is available round the clock to support your OEM needs. Our team of experts at WOC is happy to assist you with any of your automation requirements. For pricing and availability on parts and repairs, kindly contact our team by phone or email.

FREQUENTLY ASKED QUESTIONS:

What kind of power supply does the Genius I/O Adapter Board require?

The Genius I/O Adapter Board typically requires a regulated DC power supply, with voltage requirements depending on the devices connected to it. Common voltages are 5V or 3.3V, though some boards may also support other voltage levels. It is important to ensure that the power supply can provide sufficient current to power all connected devices.

How do I program the Genius I/O Adapter Board?

Programming the Genius I/O Adapter Board typically involves writing software for the microcontroller or processor it's connected to. You can use an Arduino, Raspberry Pi, or any other compatible microcontroller to interact with the board. Communication with the board can be done using libraries and APIs that support I2C, SPI, UART, and GPIO communication.

Can I use multiple sensors or devices with the Genius I/O Adapter Board?

Yes, the board is designed to support multi-device connections. It can handle multiple peripherals connected through protocols like I2C, SPI, and GPIO. The board may use techniques like multiplexing, daisy-chaining, or bus-sharing to manage multiple devices with minimal wiring.
