IC697PWR724(E) - Power Supply Module is available in stock which ships the same day.
IC697PWR724(E) - Power Supply Module comes in UNUSED as well as REBUILT condition.
To avail our best deals for IC697PWR724(E) - Power Supply Module, contact us and we will get back to you within 24 hours.
Part No.: IC697PWR724(E)
Manufacturer: General Electric
Product Type: Power Supply Module
Nominal Rated Voltage: 24 volts DC
Input Voltage Range: 18 to 32 VDC
Input Power: 160 watts at full load
Output power: 90 watts
Location on Baseplates: Leftmost slot
DC Output: +5VDC, +12 VDC, -12 VDC
Availability: In Stock
Series: VersaMax
IC697PWR724(E) is a Power Supply Module developed by GE. It is a 90 Watt, 24 VDC Power Supply Module from the GE Fanuc 90-70 Series. Designed to provide reliable power to VME-based systems, this module is ideal for industrial automation setups requiring high output and consistent power stability. It offers three output voltage options, compact installation, and built-in protections to enhance operational safety and efficiency.
The IC697PWR724 operates from a 24 VDC nominal line. It accepts an input voltage range of 18 to 32 VDC and draws up to 160 watts at full load. The module is also equipped with an inrush energy limiter to prevent damage during start-up, with a maximum inrush energy of 22 joules, ensuring reliable power delivery right from the moment it’s activated.
With a total output capacity of 90 watts, the IC697PWR724 provides three distinct voltage outputs to meet a wide range of operational needs. It delivers +5 VDC with a maximum current of 18 amps for core system functions, +12 VDC at up to 1.5 amps, and -12 VDC at up to 1 amp. The output ranges are tightly controlled, with +5 VDC ranging from 4.90 to 5.25 VDC, +12 VDC from 11.75 to 12.6 VDC, and -12 VDC from -11.75 to -12.6 VDC. These outputs provide power for different components within the VME rack, ensuring all system parts receive the required voltages for smooth operation.
To safeguard connected components, equipped with multiple layers of protection. Overvoltage protection is set between 5.7 and 6.7 volts on the +5 VDC output, guarding against voltage surges. Additionally, overcurrent protection ensures safe operation by limiting currents to 26 amps on the +5 VDC output, 4 amps on the +12 VDC output, and 2 amps on the -12 VDC output. These protective limits help prevent component damage and improve the overall longevity and reliability of the power supply system.
Engineered to withstand short-term power interruptions. It provides a 10-millisecond ride-through time at a minimum input voltage of 20 VDC, ensuring system continuity during brief power losses. This feature is essential for environments where even a short lapse in power could lead to data loss or system faults, as it maintains steady power flow until the input is stabilized.
Installation is straightforward, thanks to the module’s slide-in, rack-mount design. It occupies the leftmost slot in the VME rack baseplate and connects via a 48-pin backplane-mounted connector. It can be used in a single-rack setup and also has the flexibility to power a second rack using a prewired cable (part number IC697CBL700), provided that the combined load does not exceed the power supply’s rated capacity. This allows for a streamlined setup and versatility for expanding system needs.
The power supply module is designed to operate across various temperatures, but when ambient conditions exceed 50°C (122°F), the output power must be derated to avoid overheating. Specific derating guidelines are provided in the installation manual to ensure safe and reliable operation. Adhering to these instructions is crucial for maximizing module lifespan and maintaining optimal performance in high-temperature environments.
It meets the VME (Versa Module Europa) standard C.1, a widely used specification in industrial automation, ensuring compatibility with VME-based systems. This makes it an effective choice for operations requiring high integration and standardized equipment within the GE Fanuc 90-70 Series.
The WOC team is always available to help you with your Mark I and II requirements. For more information, please contact WOC.
What is IC697PWR724(E)?
It is a Power Supply Module developed by GE under VersaMax series.
Can the Module continue operating during a temporary power loss?
Yes, it features a ride-through time of at least 10 milliseconds at a minimum input of 20 VDC, allowing it to maintain power briefly during a loss of input voltage, ensuring continuity for critical operations.
Where is the Module installed within the VME rack?
The Module is designed to be installed in the leftmost slot of the rack. It connects to the backplane via a 48-pin connector for streamlined integration.
Can the Module power a second rack?
Yes, it can support a second rack if the total power load across both racks remains within the 90-watt output limit.
