IC660BBA023 - Thermocouple Input Genius I/O Block

SPECIFICATIONS

Part Number: IC660BBA023
Manufacturer: GE Fanuc
Series: Genius I/O
Product Type: Thermocouple Input Block
Block Power: 24/48 V DC
Weight: 4 Pounds
Number of Inputs: 6

IC660BBA023 is a 24/48 Volts DC Thermocouple Input Block Manufactured by GE Fanuc Genius I/O Series. This block is mostly used for temperature monitoring because the inputs are connected to common thermocouple kinds. It can also be used to measure low-voltage signals as input signals. During operation, it dissipates a maximum of 9 Watts of heat. The power supply's voltage range is 24 to 48 volts DC, with a maximum ripple of 10% and a power supply dropout time of 10 milliseconds. This block's six input circuits are separated into three groups, each of which includes a thermocouple input circuit and a remote cold junction compensation input. The IC660BBA023 Thermocouple Input Block's input voltage measurement range is -25 mV to 150 mV, and the input channels' precision at 25 degrees Celsius is 8 Hertz.

• It also has a normal input update time of 2 seconds and a maximum update time of 3 seconds. The internal cold junction inputs measure a temperature range of 0 to 60 degrees Celsius with a resolution of less than 0.01 degree Celsius and a precision of +/- 0.1 degree Celsius.

• The module's CPU is in charge of converting cold junction temperature values into voltage values. It is compatible with the GE IC697 series PLCs. Make sure there's enough airflow for air conditioning during installation.

• The module's ambient operating temperature ranges from 0 to 60 degrees Celsius, with a relative humidity range of 5% to 95%. Terminals 5 and 6 of the IC660BBA023 Thermocouple Block can be linked to a DC power supply ranging from 24 to 48 volts.

WOC has the largest stock of GE Fanuc Automation spare parts and we can repair your faulty spares with a warranty. WORLD OF CONTROLS can also supply UNUSED and REBUILT components backed up with a warranty. Our team of experts is available round the clock to support your urgent needs related to critical spares, contact us.

FREQUENTLY ASKED QUESTIONS

What is GE Fanuc IC660BBA023?

It is a 24/48 Volts DC Thermocouple Input Block mostly used for temperature monitoring because the inputs are connected to common thermocouple kinds.

What is the number of input circuits in the Block?

There are six input circuits in this block.

What are the characteristics of each group?

Two thermocouple input circuits and two remote cold junction compensation inputs are included in each group.
