DS200DMCBG1AED - Digital Exciter Main Control Board is available in stock which ships the same day.
DS200DMCBG1AED - Digital Exciter Main Control Board comes in UNUSED as well as REBUILT condition.
To avail our best deals for DS200DMCBG1AED - Digital Exciter Main Control Board, contact us and we will get back to you within 24 hours.
SPECIFICATIONS:
Part Number: DS200DMCBG1AED
Manufacturer: General Electric
Series: EX2000
Product Type: Digital Exciter Main Control Board
Number of channels: 16
Analog output current: 0-20 mA
Operating temperature: -30 to 65 °C
Size: 10.16 cm wide x 33.02 cm
Frequency: 50 or 60 Hz
Repair: 3-7 Day
Availability: In Stock
Weight: 2 lbs
Country of Origin: United States
Manual: GEH-6120B
FUNCTIONAL DESCRIPTION:
DS200DMCBG1AED is a Digital Exciter Main Control Board manufactured and designed by General Electric as part of the EX2000 Series used in GE Excitation Turbine Control Systems. The IOS+/IEI units use DS200-based 10s hardware printed wiring boards (boards) with physical packaging and performance enhancements over the previous versions of the 10s. These two units provide the features of the 10s in applications requiring panel mounting using the IEI and door/desk mounting using the IOS+. Both units support expanded I/O, an additional 32 input points, and 28 outputs. The operation of IOS+ and IEI is almost identical to the DS200-based 10s. The IOS+ and IEI are composed of three major boards and several optional boards. The DS200DMCB is the Main Control Board (DMCB) of IOS, IOS+, and IEI units. The primary functions of the DMCB board are to supply the control power requirements and to provide an interface and a data processing unit for the following information paths:
The dominant microprocessor (DUP) and the LAN microprocessor (LUP). The DUP is an Intel 8OC186 running at a clock rate of 33 MHz. Most of the circuitry on this board is associated with this processor. The LUP) is an 8OC196 processor operating at a clock frequency of 15.667 MHz. LUP is the drive DLAN and DLAN+ communication processor. Direct operator interface is provided in two forms, one with the DS200KLDB board (KLDB), and one with the DS200DKLB board DKLB). The KLDB board has 32 configurable keys with state LEDs, 6 configurable lo-character displays, and a seventh diagnostic display with a 16-key keypad. A variation of this board is the DS200DKLB Board.
The DKLB provides the same functionality as the KLDB with a reduced number of keys and displays. Both boards use the keyboard microprocessor (KUP), an 8OC196 microprocessor operating at a clock frequency of 11.059 MHz. to provide key, display, and LED functions. An auxiliary power supply module provides the conversion from the 115/230 ac line voltage to the 19 V ac CT control power required by the main unit. The ac line is connected directly to the DS200DPCB power connect board. A 3-wire ac control power connection is made between this module and 1TB on the main unit. LAN connection points are provided on 1TB. Except for I/O and RS-232C, connect directly to the DMCB board and IOEA board if present, all external wiring connects to this terminal board.
WOC has the largest stock of GE Excitation Control System Replacement Parts. We can also supply unused and rebuilt backed-up with a warranty. Our team of experts is available round the clock to support your OEM needs. Our team of experts at WOC is happy to assist you with any of your automation requirements. For pricing and availability on parts and repairs, kindly contact our team by phone or email.
