30000-00-20-36-02 - Proximity Probe Sensor

SPECIFICATIONS

Part Number: 30000-00-20-36-02
Manufacturer: Bently Nevada
Product Type: Proximity Probe Sensor
Country of Manufacture: USA (United States)

Functional Description

30000-00-20-36-02 is a Proximity Probe Sensor manufactured by Bently Nevada. Equipped with high-temperature ClickLoc connectors, the probe provide robust and secure connections. These connectors are designed to endure extreme temperatures and environmental stress. To prevent contamination, each probe and cable come with connector protectors and a disposable connector protector installation tool, ensuring the connectors remain clean and functional during installation and operation.

Key Components and Materials

• 1. Probe Tip Material: The probe tip is made of Polyetheretherketone (PEEK), a highly durable and heat-resistant polymer. This ensures the tip withstands harsh operating conditions while maintaining its precision and structural integrity.
• 2. Probe Case Material: The probe case is constructed from AISI 304 Stainless Steel (SST). This material offers excellent corrosion resistance and durability, making it suitable for environments exposed to high temperatures, chemicals, and mechanical stress.
• 3. Probe Cable Specifications: The probe is equipped with a 75 ohm triaxial cable insulated with Perfluoroalkoxyethylene (PFA). This insulation provides exceptional resistance to heat, chemicals, and moisture. The FluidLoc technology in the cable prevents moisture ingress, ensuring signal integrity and extended sensor lifespan.

Temperature Ratings

• 1. Operating and Storage Temperature: The proximity probe is designed to operate and be stored in temperatures ranging from -35°C to +200°C (-31°F to +392°F). This wide range ensures the probe functions effectively in both extreme cold and high-temperature environments.
• 2. Short-Term Temperature Tolerance: The probe can tolerate short-term operating and storage temperatures of up to +250°C (482°F) for less than 24 hours. This capability is vital for applications with temporary exposure to elevated temperatures, such as during startup or abnormal operating conditions.

Advantages

• High Durability: Constructed with premium materials like PEEK and AISI 304 SST, the probe offers long-lasting performance under demanding conditions.
• Exceptional Temperature Resistance: The ability to function across a broad temperature range ensures reliability in extreme operational scenarios.
• Reliable Cable Technology: The 75 ohm triaxial PFA-insulated FluidLoc cable minimizes signal loss and prevents moisture ingress, maintaining consistent performance over time.
• Versatile Length Options: The availability of different cable lengths allows for flexibility in installation across varied industrial setups.
• Corrosion Resistance: The stainless-steel construction resists corrosion, enhancing the sensor's lifespan even in chemically aggressive environments.

World of Controls has the most comprehensive catalog of Bently Nevada Replacement parts. Our professionals are standing by to help you with your needs. If you require any additional information, please contact WOC.

FREQUENTLY ASKED QUESTIONS

What is 30000-00-20-36-02?
It is a 3300 XL Standard Proximity Probe Sensor manufactured by Bently Nevada.

Are there specific tools provided for connector installation?
Yes, each probe and cable come with a disposable connector protector installation tool, which ensures proper and contamination-free installation of the connectors.

Do the threaded cases include any safety features?
Yes, the threaded cases come with a locknut with pre-drilled holes for safety wire, ensuring secure installation and preventing accidental loosening.

How does the removable collar on the ClickLoc connector help during installation?
The removable collar allows for easier routing of the cable through tight clearances or confined spaces, making the installation process more convenient and flexible.

Can the probe withstand harsh industrial conditions?
Absolutely. The 3300 XL 25 mm probe is specifically designed to endure harsh steam turbine drive-end environments, including high temperatures and challenging operating conditions, without compromising reliability or performance.
