173C8536ALG3 - Backplane with Rack

SPECIFICATIONS

Part No.: 173C8536ALG3
Manufacturer: General Electric
Country of Manufacture: United States of America (USA)
Product Type: Backplane with Rack
Availability: In Stock
Series: Innovation series

Functional Description

173C8536ALG3 is a Backplane with Rack developed by GE. It is a part of innovation series. It is designed with the VME (Versa Module Europa) standard. The backplane provides the necessary physical and electrical support for modules and systems within a control rack, ensuring that each component is securely installed and effectively connected for optimal performance.

Features

• VME Subrack PWM2 Configuration: Configured as a VME Subrack PWM2, which is designed to accommodate and organize multiple VME-based modules in a rack-based environment. This configuration supports the VME standard, a popular choice in industrial automation, embedded computing, and telecommunications systems.
• Modular Design: The backplane features a modular design, allowing for flexible system configurations and easy upgrades. It can support various types of input/output modules, communication interfaces, and processing units, depending on the specific requirements of the control system.
• High Reliability: The backplane is built with durability and reliability in mind. It is constructed using high-quality materials to withstand industrial environments, ensuring long-term performance and minimizing the risk of downtime.
• Efficient Signal Distribution: The backplane provides a highly efficient signal distribution network, ensuring that data and power are seamlessly transmitted between the various modules in the system. This feature is critical for maintaining high operational efficiency in industrial automation applications.
• Versatility and Scalability: Designed to handle a wide range of applications, the backplane is scalable to meet the growing needs of control systems. It can be expanded by adding additional modules or racks, making it an ideal solution for both small-scale and large-scale industrial automation systems.
• Compatibility: The backplane is fully compatible with other GE products and systems within the Innovation Series, making it a versatile choice for those looking to build or upgrade their control systems with cutting-edge technology.

The WOC team is always available to help you with your Mark IV requirements. For more information, please contact WOC.

Frequently Asked Questions

What is 173C8536ALG3?
It is a Backplane with Rack developed by GE.

What is the VME Subrack PWM2 configuration?
The VME Subrack PWM2 configuration refers to a modular framework for housing and connecting various VME modules within a control system. This backplane follows the VME standard, ensuring compatibility with other VME-based components and systems in the industrial environment.

How does the backplane ensure reliable operation?
Constructed from high-quality materials to provide durability and resistance to environmental stress. It ensures efficient signal distribution and power supply to connected modules, which is essential for maintaining operational reliability in critical systems.
