IS410TBCIS2C - Contact I/O Terminal Board

SPECIFICATIONS:

Part Number: IS410TBCIS2C
Manufacturer: General Electric
Series: Mark VIeS
Product Type: Contact I/O Terminal Board
Number of channels: 12
Technology: Surface-mount
Maximum Lead Resistance: 15Ω
Analog output current: 0-20 mA
Operating temperature: -30 to 65 °C
Size: 15.9 cm high x 17.8 cm wide
Frequency: 50 or 60 Hz
Humidity: 5 to 95%
Repair: 3-7 Day
Availability: In Stock
Weight: 2 lbs
Country of Origin: United States

FUNCTIONAL DESCRIPTION:

IS410TBCIS2C is a Contact I/O Terminal Board manufactured and designed by General Electric as part of the Mark VIe Series used in GE Distributed Turbine Control Systems. A Contact I/O Terminal Board, also known as an I/O terminal block or I/O terminal strip is a device used in industrial automation and control systems. It provides a central location for connecting input and output signals between field devices and the control system. The I/O terminal board typically consists of a series of screw terminals or spring-clamp connectors arranged in rows or columns. Each terminal is labeled and designated for specific types of signals, such as digital inputs, digital outputs, analog inputs, or analog outputs. Field devices, such as sensors, switches, actuators, or relays, are wired to the appropriate terminals on the I/O terminal board. This centralized wiring configuration simplifies installation, maintenance, and troubleshooting of the control system. The I/O terminal board acts as an interface between the field devices and the control system's I/O modules or controllers. The control system can read the status of input signals from the field devices and send output signals to control the field devices through the terminal board connections.

FEATURES:

Contact I/O Terminal Boards come with various features depending on the specific model and manufacturer. Here are some common features you may find in a Contact I/O Terminal Board:

• Terminal Configuration: They typically have a modular design with multiple terminal slots or channels for connecting input and output signals. Each channel usually consists of a set of screw terminals or spring-clamp connectors.

• Input and Output Compatibility: Contact I/O Terminal Boards support a wide range of input and output types, such as digital inputs (DI), digital outputs (DO), analog inputs (AI), analog outputs (AO), relay outputs, thermocouple inputs, etc. The terminals are designed to accommodate different signal levels and voltage/current requirements.

• Number of Channels: Terminal boards can vary in the number of channels they provide, ranging from a few channels to dozens or more. The number of channels determines how many field devices can be connected to the board.

• Mounting Options: They often feature mounting options, such as DIN rail mounting or panel mounting, for easy installation in control cabinets or panels.

• Software Compatibility: Certain Contact I/O Terminal Boards may have compatibility with specific software platforms or programming environments, facilitating easy integration into the overall control system architecture.

WOC has the largest stock of GE Distributed Turbine Control System Replacement Parts. We can also repair your faulty boards. WORLD OF CONTROLS can also supply unused and rebuilt backed-up with a warranty. Our team of experts is available round the clock to support your OEM needs. Our team of experts at WOC is happy to assist you with any of your automation requirements. For pricing and availability on any parts and repairs, kindly get in touch with our team by phone or email.

FREQUENTLY ASKED QUESTIONS:

What is an I/O Terminal Board?

An I/O (Input/Output) Terminal Board is a hardware component used in electronic systems to facilitate connections between various input and output devices and the central processing unit (CPU) or controller.

What are the common applications of I/O Terminal Boards?

I/O Terminal Boards find applications in industrial automation, robotics, embedded systems, and other electronic control systems where multiple sensors, actuators, and devices need to communicate with a central processing unit.

What types of connections does an I/O Terminal Board support?

I/O Terminal Boards typically support various types of connections such as digital inputs/outputs (DI/DO), analog inputs/outputs (AI/AO), serial communication ports (RS-232, RS-485), Ethernet, and other specialized interfaces depending on the specific requirements of the application.
