IC3606SPCD1E - Peripheral Component Interconnect Expansion Board

SPECIFICATIONS:

Part No: IC3606SPCD1E
Manufacturer: General Electric
Product Type: Peripheral Component Interconnect Expansion Board
Series: Mark I & II
Input Voltage: 100-240V AC, 50/60Hz
Output Current: 0.15 A AMP
Output Voltage Range: 0-50V DC
Operating Temperature: 0°C to 40°C
Resolution: 10mV/10mA
Availability: In Stock
Weight: 2.5 kg
Dimensions: 6.00 x 6.00 x 5.00
Country of Origin: USA

FUNCTIONAL DESCRIPTION:

IC3606SPCD1E is a Peripheral Component Interconnect Expansion Board manufactured and designed by General Electric and is part of the Mark II Series used in Static Starter Control systems. The Peripheral Component Interconnect (PCI) Expansion Board is a crucial hardware component designed to extend the functionality of a computer system by providing additional PCI slots. This expansion allows users to install various PCI cards, such as graphics cards, network cards, or storage controllers, thereby enhancing the system's performance and capabilities. By integrating a PCI Expansion Board, users can upgrade their systems to meet evolving needs, whether for increased processing power, additional connectivity options, or enhanced data storage capabilities. This component is essential for systems requiring additional expansion slots beyond the built-in ones, enabling more versatile and customizable hardware configurations.

FUNCTIONS AND FEATURES:

• Expansion Capabilities: It provides additional PCI slots to accommodate extra peripheral cards, expanding the system's overall capacity and functionality.

• Signal Processing: The board supports the integration of various signal-processing components, allowing for the processing and management of multiple signals within the control system.

• System Integration: It facilitates the connection of additional hardware components to the existing control system, enhancing system flexibility and performance.

• Reliability and Durability: Designed to operate in demanding industrial environments, the PCI Expansion Board is built to withstand harsh conditions and ensure reliable performance.

• Compatibility: The board is specifically engineered to be compatible with GE's Mark IV control systems, ensuring seamless integration and operation within the established infrastructure.

• Enhanced Performance: Adding extra PCI slots, enables the system to handle more complex tasks and workloads, improving overall efficiency and capability.

WOC has the largest stock of replacement parts for GE Speedtronic Gas turbine control systems. We can also repair your faulty boards and supply unused and rebuilt boards backed up with a warranty. Our team of experts is available round the clock to support your OEM needs. Our team of experts at WOC is happy to assist you with any of your automation requirements. For pricing and availability on parts and repairs, kindly contact our team by phone or email.

FREQUENTLY ASKED QUESTIONS:

What are the main functions of this expansion board?

The board enhances system performance by enabling the addition of extra peripheral components, supporting advanced signal processing, and integrating new hardware into the existing control system.

What types of peripheral cards can I install on the IC3606SPCD1E?

The board supports various PCI peripheral cards, such as graphics cards, network cards, or storage controllers. Ensure that the cards are compatible with the system and the expansion board.

How do I ensure proper cooling for the PCI Expansion Board?

Ensure adequate airflow and cooling within the system’s chassis. The board should be installed in a well-ventilated area of the chassis to prevent overheating.
