SPECIFICATIONS
Part No: IC3603A111A
Manufacturer: General Electric
Function: Diode Assembly
Series: Mark I and II
Repair: 3-7 Day
Availability: In Stock
Country of Manufacturer: United States (USA)
Functional Description
IC3603A111A is a Diode Assembly developed by GE. It is a part of Mark I and II control system. Its role in managing electrical current, ensuring reliability, and safeguarding critical operations underscores its importance in industrial and automation settings. The board contributes to the overall efficiency and dependability of these control systems.
System Front Panel Features
- VMPA/VMPC PWB Symbol: The front panel of the test module features a symbol representing the VMPA/VMPC Printed Wiring Board (PWB) that is mounted within the turbine control panel. This symbol serves as a visual reference to indicate the specific PWB being tested.
- LED Signal Indicators: On the test module's front panel, there are LED indicators that display the presence of signals on the input and output lines of the VMPA/VMPC PWB. These LEDs illuminate to provide a real-time status of signal activity, helping operators quickly identify any issues or anomalies.
- VMPA/VMPC Toggle Switch: To ensure accurate testing, a VMPA/VMPC toggle switch is provided on the test module. It allows operators to select the specific position corresponding to the type of PWB installed in the turbine control panel under test. This ensures that the test module is aligned with the correct hardware configuration.
- MONITOR/FIRST FLT DET Switch: This switch on the test module serves as a mode selector, allowing users to choose between different operating modes. Depending on the specific requirements of the test or monitoring task, operators can toggle between the MONITOR and FIRST FLT DET modes to access the desired functionality.
- LAMP TEST Pushbutton: For the purpose of verifying the integrity of all LED indicators, a LAMP TEST pushbutton is provided on the test module. When pressed, it initiates a test that checks the functionality of the LEDs. This test can be performed whenever the test module is powered on. During the test, the LEDs that were already illuminated will remain steady, while the others will flash on and off. This design conserves power and helps identify any malfunctioning LEDs.
- Jacks J1 and J2: The front panel of the test module also features two jacks, J1 and J2. These jacks have distinct sizes to prevent the accidental connection of cables to the wrong jack. The varying sizes serve as a safety feature to ensure that the correct cables are connected to the appropriate jacks, avoiding any potential errors or damage during testing and monitoring activities.
System Back Panel Features
- Extender Board Storage Space: The back panel of the test module is ingeniously designed to incorporate storage space for the extender board. This feature ensures that the extender board, a crucial accessory for extending and enhancing the capabilities of the test module, is always readily available when needed. It prevents misplacement and provides a dedicated space for safekeeping.
- Stand Functionality: One of the standout features of the back panel is its dual-purpose design. Not only does it house the extender board, but it also acts as a reliable stand for the test module. This stand extends outward, creating a stable and secure platform that supports the test module in an upright position during use. This ergonomic design not only promotes efficient operation but also minimizes the risk of accidental tipping or damage to the module.
- Operating Instructions: Recognizing the need for quick and easy reference during the operation of the test module, an abbreviated set of operating instructions is thoughtfully included on the back panel. These concise instructions offer users a handy reference point for understanding the fundamental procedures and functions of the equipment. This feature is especially valuable for operators who may need a quick reminder or newcomers who are learning to use the module for the first time.
- User-Friendly Design: The integration of these elements on the back panel reflects a user-centric design approach. It streamlines the workflow by providing easy access to essential components and information while ensuring that the test module can be set up and utilized efficiently. This user-friendliness is a critical aspect of equipment design, as it minimizes downtime and maximizes productivity.
WOC is happy to assist you with any of your GE requirements. Please contact us by phone or email for pricing and availability on any parts and repairs.
FREQUENTLY ASKED QUESTIONS
What is IC3603A111A?
It is a Diode Assembly developed by GE
What is the purpose of the extender board storage space on the back panel?
The extender board storage space is designed to securely hold the extender board, which extends and enhances the capabilities of the test module. This ensures that the extender board is always accessible, preventing misplacement and offering a dedicated spot for safekeeping.
Are operating instructions included on the back panel of the test module?
Yes, Operating instructions are provided on the back panel for quick reference during the operation of the test module. These concise instructions offer users a convenient guide for understanding fundamental procedures and functions.
What are the benefits of the user-friendly design incorporated into the back panel?
The user-friendly design of the back panel prioritizes ease of use and accessibility. It streamlines the workflow by providing easy access to essential components and information.
