IC3600STKD1 - Temperature Control Card

SPECIFICATIONS:

Part Number: IC3600LTDA1
Manufacturer: General Electric
Series: Mark II
Product Type: Temperature Control Card
Input Voltage Range: 24 VDC
Operating Temperature: -20°C to +55°C
Board Size: 16.51 cm High x 17.8 cm
Number of Inputs: 2-4 channels
Supported Sensors: Thermocouples (Types J, K, T,)
Repair: 3-7 Days
Country of Origin: USA
Availability: In Stock

FUNCTIONAL DESCRIPTION:

IC3600STKD1 is a Temperature Control Card manufactured and designed by General Electric as part of the Mark II Series used in GE Speedtronic turbine control systems. These modular temperature controller cards are designed for integration into a host mainframe. They include either one or two separate temperature controllers, each capable of driving a thermoelectric cooler. The controllers are equipped with a bi-polar current driver that is compatible with most modules, providing accurate temperature control across a broad temperature spectrum. The temperature controllers utilize thermistor-type temperature sensors exclusively and offer features such as module voltage measurement, the ability to select the thermistor current range, and adjustable control loop gain settings ranging from 1 to 127.

• Temperature controllers capable of handling TEC currents of up to 3A
• The bi-polar current driver ensures accurate temperature regulation
• Adjustable control loop gain settings ranging from 1 to 127
• Maintains optimal temperature for laser diodes
• Compatible with LDC-3908 and LDC-3916 modular laser diode controllers

CONNECTIONS:

The rear panel of these controller cards features 15-pin connectors for interfacing with thermoelectric cooler modules and their corresponding thermistors. These connectors include options for current drive and temperature sensors and connections to earth ground (chassis) and the module's analog ground. The pins for the module are electrically isolated from the chassis ground, giving users the flexibility to connect either output terminal to earth ground if desired. The response of Modular Laser Diode Cards to sensing different limits can be managed through the GPIB interface. Users can configure most high-limit responses to either shut off the source or provide a limit warning via the GPIB interface.

FEATURES AND BENEFITS:

• High Voltage Thermocouple Protection – Fused
• High Current Protection – Fused
• Power Disabled to Heater under the following conditions: Heater is open, high amperage situation, triac failure, or over-temperature condition
• All features and parameters are fully adjustable via the keypad menu
• Amperage measurement and display
• Percentage of power shown on display
• Supports both automatic and manual operation
• Anti-arching functionality
• Boot and standby modes
• Temperature ranges available in Fahrenheit or Celsius
• Compatible with “J” or “K” thermocouple types
• Panel lockout for selectable features

WOC has the largest stock of GE Speedtronic gas turbine control systems OEM replacement parts. We can also repair your faulty boards and supply unused and rebuilt boards backed up with a warranty. Our team of experts is available round the clock to support your OEM needs. Our team of experts at WOC is happy to assist you with any of your automation requirements. For pricing and availability on any parts and repairs, kindly contact our team by phone or email.

FREQUENTLY ASKED QUESTIONS:

What is high-voltage thermocouple protection?

High-voltage thermocouple protection helps prevent damage to thermocouples by incorporating fuses that safeguard against excessive voltage.

How does high current protection work?

High current protection utilizes fuses to interrupt power flow if the current exceeds safe limits, protecting both the device and connected components.

Under what conditions is power disabled to the heater?

Power to the heater is automatically disabled in cases of an open heater, high amperage, triac failure, or when an over-temperature condition is detected.
