DS3800NPSV - Power Supply Module

SPECIFICATIONS:

Part Number: DS3800NPSV
Manufacturer: General Electric
Series: Mark IV
Product Type: Power Supply Module
Number of channels: 12
Operating temperature: -30 to 65 degrees Celsius
Size: 8.25 cm high x 4.18 cm
Repair: 3-7 Day
Availability: In Stock
Weight: 2 lbs
Country of Origin: United States

FUNCTIONAL DESCRIPTION:

DS3800NPSV is a Power Supply Module manufactured and designed by General Electric as part of the Mark IV Series used in GE Speedtronic Gas Turbine Control Systems. A power supply module, also known as a power supply unit (PSU), is an electronic device that converts electrical power from a source (such as a wall outlet or a battery) into the specific voltage and current required by various electronic devices. It provides a stable and reliable power source to ensure the proper functioning of the connected equipment. Power supply modules are used in a wide range of applications, including computers, telecommunications equipment, industrial machinery, consumer electronics, and many other electronic systems. They are available in various sizes, power ratings, and form factors to accommodate different requirements.

FEATURES OF POWER SUPPLY MODULE:

Input Stage: This stage includes components like transformers, rectifiers, and filters that convert the incoming AC (alternating current) power from the electrical grid into a DC (direct current) voltage suitable for the power supply module.

Control Circuitry: Power supply modules often include control circuitry that regulates the output voltage and current to ensure stability and protect connected devices from power fluctuations, overvoltage, and overcurrent conditions. This circuitry may include voltage regulators, current limiters, feedback loops, and protection mechanisms.

Output Stage: The output stage of a power supply module provides the desired DC voltage and current to the connected devices. It typically consists of voltage and current regulation circuits, output connectors, and filtering components to reduce noise and ripple in the output.

Efficiency: Power supply modules are rated for their efficiency, which indicates how effectively they convert input power to output power. Higher efficiency power supplies waste less energy as heat, resulting in lower operating costs and reduced environmental impact.

Safety and Protections: Power supply modules often incorporate safety features and protections, such as short circuit protection, overvoltage protection, overcurrent protection, and temperature monitoring to prevent damage to the power supply module and connected devices.

WOC maintains the largest inventory of Replacement parts for GE Speedtronic control systems. Additionally, we offer warranty-backed unused and rebuilt boards as well as board repairs for your damaged ones. For your OEM needs, our team of professionals is available around-the-clock. We at WOC are happy to help you with any needs you may have in terms of automation. Please contact our team by phone or email for pricing and availability on any components and repairs.

FREQUENTLY ASKED QUESTIONS:

What is the purpose of a power supply module?

A power supply module converts electrical power from a source into the specific voltage and current required by electronic devices. It ensures a stable and reliable power source for the proper functioning of the connected equipment.

What is the importance of efficiency in power supply modules?

Efficiency is a measure of how effectively a power supply module converts input power to output power. Higher efficiency means less energy is wasted as heat, resulting in lower operating costs and reduced environmental impact. It is important to choose a power supply module with high efficiency for energy-efficient operation.

How to Check Price and Availability For DS3800NPSV?

Please Contact World of Controls FZE for sales at +1 609 385 1231 or Request a Quote.
