Components
- 3500/05 Instrument Rack: The foundational rack that houses all system modules and provides structural integrity for the installation.
- 3500/15 Power Supplies: One or two power supplies can be configured to support system redundancy, ensuring continuous power for critical monitoring functions.
- 3500/22M Transient Data Interface (TDI) Module: The TDI module facilitates data collection and transfer, essential for transient analysis and data management.
- 3500/XX Monitor Modules: These modules are configured to monitor various parameters, such as vibration, temperature, and position, allowing for tailored monitoring based on specific machinery needs.
- 3500/32M (4-channel) or 3500/33 (16-channel) Relay Modules: Relay modules provide alarm and shutdown relays for the system, enabling customized alert responses based on critical thresholds.
- 3500/25 Keyphasor Modules: One or two modules may be added to measure shaft speed and phase reference, supporting diagnostic accuracy for rotating equipment.
- 3500/92 Communication Gateway Modules: These modules enable seamless integration with plant control and automation systems, facilitating real-time data sharing and enhancing connectivity.
- Input/Output (I/O) Modules: I/O modules manage the communication between monitor modules and the machinery, ensuring reliable data transmission.
- 3500/94M VGA Display: A display option to visually monitor data directly from the system, providing on-site access to critical information.
- Intrinsic Safety Barriers or Galvanic Isolators: For installations in hazardous areas, these barriers or isolators ensure safe operation without compromising system performance.
- 3500 System Configuration Software: Essential software for setting up and customizing system parameters, enabling precise configuration and easy adjustments.
Bently Nevada 3500 Spares Applications
- Industrial Gas and Steam Turbines: These turbines, often found in power generation and mechanical drive services, are essential for energy production and require precise monitoring to ensure optimal efficiency and safety.
- Aeroderivative Gas Turbines: Used in both power generation and mechanical drive applications, aeroderivative turbines benefit from the 3500 System�s robust monitoring to detect early signs of wear or failure.
- Hydro-electric Turbines: Operating in hydroelectric power generation, these turbines depend on continuous monitoring to maintain efficiency and ensure machinery protection against potential damage in water-driven environments.
- Air or Process Gas Compressors: The 3500 System monitors both radial and axial compressors, as well as centrifugal and positive displacement types, safeguarding critical equipment in industries requiring pressurized gas.
- Turbo Expanders: These machines, which manage gas expansion in various processes, rely on the 3500 System to ensure stable and efficient operation while mitigating potential risks of mechanical issues.
- Electric Motors and Generators: Widely used across industrial applications, these machines benefit from monitoring to manage performance and prevent downtime, especially in heavy-duty operational environments.
- Exciters: Often coupled with generators, exciters are essential for electrical output control, and the 3500 System provides the necessary monitoring for maintaining stability and operational safety.
- Gear Boxes: As a key component in mechanical power transmission, gear boxes are monitored for vibration, temperature, and other factors to prolong their operational lifespan and prevent costly repairs.
- Pumps (Centrifugal and Positive Displacement): Found in numerous industries, pumps are essential for fluid movement, and the 3500 System�s monitoring capabilities prevent failure in both centrifugal and positive displacement types.
- Fans and Blowers: These machines, crucial for ventilation and cooling, benefit from the system�s monitoring to detect imbalances, mechanical wear, and prevent overheating.
- Reciprocating Compressors: Common in the oil and gas industry, reciprocating compressors require precise monitoring due to their complex operation and susceptibility to vibration and pressure changes.
- Extruders and Pelletizers: Used in manufacturing processes for shaping materials, these machines rely on the 3500 System to monitor for consistency and efficiency, particularly in plastic and food production sectors.
World of Controls has the most comprehensive spare parts for the Bently Nevada 3500 spares. Please contact WOC if you require further details.
Frequently Asked Questions
What types of machinery can the 3500 System monitor?
The 3500 System is capable of monitoring a wide range of machinery, including industrial gas and steam turbines, aeroderivative gas turbines, hydro-electric turbines, compressors (both radial/axial and centrifugal/positive displacement), turbo expanders, electric motors and generators, exciters, gear boxes, pumps, fans, blowers, reciprocating compressors, extruders, and pelletizers.
Are Bently Nevada 3500 spares suitable for power generation applications?
Yes, the 3500 System is ideal for power generation applications and can be used with industrial gas and steam turbines, aeroderivative turbines, and hydro-electric turbines, providing continuous monitoring and protection in these high-demand environments.
Can the 3500 System be used with different types of compressors?
Absolutely. The 3500 System supports a variety of compressors, including air or process gas compressors, both radial and axial types, and centrifugal as well as positive displacement models, making it versatile for industries that rely on compression systems.
