World Of Controls understands the criticality of your requirement and works towards reducing the lead time as much as possible.
IS420ESWAH3A REV- A - 10/100 Ethernet IONet Switch is available in stock which ships the same day.
IS420ESWAH3A REV- A - 10/100 Ethernet IONet Switch comes in UNUSED as well as REBUILT condition.
To avail our best deals for IS420ESWAH3A REV- A - 10/100 Ethernet IONet Switch, contact us and we will get back to you within 24 hours.
SPECIFICATIONS:
Part Number: IS420ESWAH3A REV- A
Manufacturer: General Electric
Series: Mark VIe
Product Type: 10/100 Ethernet IONet Switch
Software: ControlST V04.03.18C
Copper Ports: 8 ports 10/100Base-TX copper, RJ-45
Power Requirements +32 V dc to 18 V dc
Memory: 256 MB DDR SDRAM
Operating System: QNX Neutrino
Mounting: DIN Rail
Operational Temperature: -40 to 70°C
Storage Temperature: -40 to 85°C
Mounting Method: DIN-rail
Dimensions: 13.8 x 8.6 x 5.6 cm
Availability: In Stock
Country of Manufacturer: United States (USA)
Manual: GEA-S1284B
FUNCTIONAL DESCRIPTION:
IS420ESWAH3A REV- A is a 10/100 Ethernet IONet Switch manufactured and designed by General Electric as part of the Mark VIe Series used in GE Distributed Gas Turbine Control Systems. These switches come in managed and unmanaged configurations. Managed switches offer advanced networking features like VLANs, QoS, and remote monitoring, making them suitable for complex network architectures. Unmanaged switches, in contrast, provide a simple plug-and-play setup for basic networking needs. Many industrial-grade Ethernet IONet switches also feature rugged enclosures, redundant power supplies, and enhanced EMC protection for reliable performance in harsh environments.
ETHERNET SWITCH FLOW CONTROL:
The switch features flow control using IEEE-defined pause packets, allowing it to regulate data transmission by responding to congestion requests and sending packets only when necessary. Designed for high reliability in industrial control systems, it boasts a mean time between failures (MTBF) of over 4 million hours at 35°C (95°F) in a stable, ground-fixed environment, ensuring long-term operational stability and minimal downtime.
CONFORMANCE CRITERIA:
The switch supports IEEE 1588 timing, enabling packet synchronization within a 1-microsecond start window. Its performance and compliance are validated based on four test criteria:
WOC maintains the largest inventory of OEM replacement parts for GE Distributed Turbine Control Systems. We also offer repair services for faulty boards and provide unused or rebuilt boards, all backed by a warranty. Our experts are available 24/7 to support your OEM requirements and assist with automation solutions. For pricing and availability on parts and repairs, please contact our team via phone or email.
What is the function of the 100 Mbps FX uplink port?
The 100 Mbps FX uplink port provides a high-speed fiber-optic connection for enhanced network backbone performance. It allows for long-distance communication, improved reliability, and reduced electromagnetic interference (EMI), making it ideal for industrial and automation applications.
What is the role of HP-MDIX auto-sensing?
HP-MDIX (Auto-Medium Dependent Interface Crossover) enables the switch to automatically detect and adjust for straight-through or crossover Ethernet cables. This eliminates the need for manually selecting cable types, simplifying installation, and reducing potential connectivity issues.
What is the maximum buffer size and MAC address capacity?
The switch is equipped with a 256KB buffer, which helps manage data flow efficiently, reducing the risk of packet loss during high-traffic conditions. It also supports up to 4K MAC addresses, allowing it to accommodate a large number of connected devices within the network.
