12HGA11J52 (GEF-2623) - Auxiliary Relay

SPECIFICATIONS

Part No.: 12HGA11J52 (GEF-2623)
Manufacturer: General Electric
Operating temperature: 0°C to 40°C
Country of Manufacture: United States of America (USA)
Product Type: Unmanaged Auxiliary Relay
Availability: In Stock

Functional Description

12HGA11J52 (GEF-2623) is a Auxiliary Relay developed by General Electric. Designed to provide reliable switching of auxiliary circuits in DC-powered control systems. With its hinged armature design, DPDT configuration, and 125 VDC voltage rating, this relay is ideal for applications requiring high performance, durability, and flexibility in controlling multiple circuits. It serves as an essential component in industrial control, power distribution, and automation systems, ensuring efficient operation in demanding environments.

Features

• Auxiliary Relay Functionality: Classified as an auxiliary relay, which means it is used to control additional circuits in electrical systems. Auxiliary relays are typically employed in control systems to provide a means of switching auxiliary contacts based on the operation of primary control relays or systems.
• Hinged Armature Design: The relay features a hinged armature, a design that allows for a more compact construction and efficient operation. The hinged armature design enhances the mechanical performance of the relay, ensuring more precise and reliable actuation when the relay is energized or de-energized.
• Double Pole Double Throw (DPDT) Configuration: The DPDT (Double Pole Double Throw) configuration allows for two independent circuits to be controlled by the same relay. This configuration provides greater flexibility and is commonly used in systems where multiple outputs need to be controlled by a single input or signal.
• Voltage Rating: Designed to operate at a voltage of 125 VDC (volts direct current), making it suitable for use in systems where DC voltage is prevalent. The 125 VDC rating ensures that the relay can handle medium voltage applications, offering a balance of power handling and efficiency.

Performance Characteristics

• Contact Configuration: The relay has a DPDT contact configuration, meaning it has two independent sets of contacts that can be used for multiple switching operations. This setup is ideal for controlling different parts of a circuit simultaneously or in sequence.
• Voltage and Current Rating: The relay is capable of handling 125 VDC, which is a common voltage in industrial and automation settings. This makes it suitable for various control and signaling applications in systems that use DC circuits.
• Durability and Reliability: General Electric's relays are known for their high durability and reliability, especially in industrial applications where consistent operation is crucial. The hinged armature design also contributes to the relay’s long lifespan and ability to withstand frequent operation cycles.

The WOC team is always available to help you with your gas turbine control system replacement parts requirements. For more information, please contact WOC.

Frequently Asked Questions

What is 12HGA11J52 (GEF-2623)?
It is a Auxiliary Relay developed by General Electric.

What type of contact configuration does the relay have?
The relay has a DPDT (Double Pole Double Throw) contact configuration. This allows it to control two independent circuits simultaneously, making it versatile for use in complex control systems.

What is the operating voltage for the relay?
The relay is designed to operate at 125 VDC (volts direct current), making it suitable for DC-powered control systems in industrial and automation environments.

What is the significance of the hinged armature?
The hinged armature design contributes to the relay's compact size and high reliability, reducing mechanical wear and enhancing performance during frequent operation cycles.
